Nome do produto: | Tubulação de aço da liga de JIS G3460 para o serviço da baixa temperatura. | Modelo não: | JIS G3460 |
---|---|---|---|
Técnica: | Estirado a frio | Tratamento de superfície: | Lubrificado |
Tipo: | Sem emenda | Liga ou não: | não liga |
Forma da seção: | círculo | Aplicação: | Para caldeiras, Superheaters, linepipes do vapor das caldeiras |
JIS G3460 Alloy Steel Pipe for low temperature service
JIS G3460 STPL380, STPL450, STPL690 Chemical Composition:
Steel Grade | Chemical Composition % | |||||
C | Si | Mn | P | S | Ni | |
STPL 380 | 0.25 max. | 0.35 max. | 1.35 max. | 0.035 max. | 0.035 max. | |
STPL 450 | 0.18 max. | 0.10~0.35 | 0.30~0.60 | 0.030 max. | 0.030 max. | 3.20 ~ 3.80 |
STPL 690 | 0.13 max. | 0.10~0.35 | 0.90 max. | 0.030 max. | 0.030 max. | 8.50 ~ 9.50 |
-JIS G3460 STPL380, STPL450, STPL690 Mechanical Property:
Steel Grade | Tensile strength |
Yield point or proof stress |
Elongation % | |||
kgf/mm2 {N/mm2} |
kgf/mm2 {N/mm2} |
No. 11 or No. 12 test piece | No. 5 test piece | No. 4 test piece | ||
Longitudinal | Transverse | Longitudinal | Transverse | |||
STPL 380 | 39 {382}min. | 21{206} min. | 35 min. | 25 min. | 30 min. | 22 min. |
STPL 450 | 46{451} | 25{245} min. | 30 min. | 20 min. | 24 min. | 16 min. |
STPL 690 | 70{686} | 53{520} min. | 21 min. | 15 min. | 16 min. | 10 min. |
