heat exchanger tubes
"
ASTM A179 3/4" estirado a frio padrão tubos do permutador de calor 14BWG
ASTM A179 3/4' 14BWG Heat Exchanger Tube Standard ASTM A179 Matrial 10# 20# etc Carbon Steel Size OD: 12.7-177.8mm WT: 1-25.4mm Length: according to customer requirement Application For Boilers,Superheaters, Heat-Exchangers, High-pressure Boilers Production Tubes are manufactured by seamless process and both hot finished and cold finished are applicable Heat treatment Hot finished tubes need not be heat treated. Cold Finished tubes are heat treated after the final cold
Tubos sem emenda do permutador de calor SUS304 de ASTM A213
TORICH ASTM A213 304 19.05x1.65 Heat Exchanger Tubes What kind of coiled tubing we can produce? unit:mm OD 4.76 WT 0.51 0.71 0.89 1.24 OD 6 WT 1 1.5 OD 6.35 WT 0.51 0.71 0.89 1.24 1.65 OD 7.94 WT 0.71 0.89 1.24 1.65 OD 9.53 WT 0.71 0.89 1.24 1.65 OD 10 WT 1 1.5 2 OD 12 WT 1 1.5 OD 12.7 WT 0.71 0.89 1.24 1.65 OD 14 WT 1 1.5 2 OD 15.88 WT 0.71 0.89 1.24 1.65 2.11 OD 16 WT 1 1.5 2 OD 19.05 WT 1 1.24 1.65 2.11 OD 25.4 WT 1.24 1.65 2.11 2.54 OD 31.8 WT 1.24 1.65 2.11 2.54 OD 38.1
Tubos de aço inoxidável sem emenda do permutador de calor Tp321 de Astm A213
ASTM A213 Seamless Stainless Steel Heat Exchanger Tubes Bright annealed stainless steel tubes as per following standard: ASTM A213 ASTM A269 EN10216-5 TC-1 Tolerance:D4/T3 (±0.5%,±0.1 min)/(±10%,±0.2 min) NDT Tests:Eddy Current or Hydraulic Test or UT Heat treatment on tubes: Bright Annealed stainless seamless tube Quality Assurance: ISO 9001&PED 97/23/EC certificated with 100% traceability on all instrument tubes and material test reports(EN 10204/3.1B)accompany every
Tubos padrão estirados a frio do permutador de calor do Od 12.7mm Astm A179
ASTM A179 Cold Drawn Heat Exchanger Tubes Advantages of tubular heat exchanger: fast heat exchange, high temperature resistance (400 ℃) and high pressure resistance (2.5MPa). Compact structure, small floor area, light weight, convenient installation and saving civil engineering investment. It has flexible design, complete specifications, strong practicability and pertinence, and saves money. Wide application conditions, suitable for large pressure, temperature range and heat
Tubos do permutador de calor de Astm A178 Q195 da caldeira, tubulação sem emenda estirada a frio
Tube Boiler ASTM A178 Heat Exchanger Tubes Material: Carbon steel and carbon manganese steel Production: Electric Resistance Welding Size range: O.D.: 12.7-127mm W.T.:0.9-9.1mm L: according to customer requirement Applications: For Boilers, Superheaters, Heat-Exchangers, Condensers, Boiler flues, Superheater flues and e ends Heat treatment: After welding, all tubes are heat treated at a temperature of 1650℉ (900℃) or higher and followed by cooling in air or in the cooling
O condensador dos tubos do permutador de calor do aço carbono de Erw conduz Astm A214 Sa214
ASTM A214 SA214 ERW Carbon Steel Heat-Exchanger Tubes Condenser Pipes Size range: O.D.:6-76.mm W.T.:0.9-19.0mm L: according to customer requirement Manufacture: Tubes are made by electric-resistance welding. Steel Grade and Chemical Compositions: C 0.18 Mn 0.27 to 0.63 P ≤0.035 S ≤0.035 Hardness Requirements: The tubes shall have a hardness number not exceeding 72HRB. Surface Condition: The finished tubes are free of scale., slight amount of oxidation is not considered as
Tubos do permutador de calor do aço carbono 1mm de ASTM A179
ASTM A179 Carbon Steel Heat Exchanger Tubes Applications: for Boilers,Superheaters,Steam linepipes of boilers Size range: O.D.:12.7-127mm W.T.:1-15mm L: according to customer requirement Steel Grade and Chemical Compositions: Grade C Mn P S Si A-1 ≤0.27 ≤0.93 ≤0.035 ≤0.035 ≥0.10 C ≤0.35 0.29-1.06 ≤0.035 ≤0.035 ≥0.10 Mechanical properties: Grade Yield Point Mpa(ksi) Tensile Strength Mpa(ksi) Elongation A-1 ≥255(37) ≥415(60) ≥30% C ≥275(40) ≥485(70) ≥30% Tolerance for OD and WT
Tubos do permutador de calor do aço carbono TORICH de ASTM A192
ASTM A192 Carbon Steel Heat Exchanger Tubes Applications: for Boilers,Superheaters,Steam linepipes of boilers Size range: O.D.:12.7-127mm W.T.:1-15mm L: according to customer requirement Steel Grade and Chemical Compositions: Grade C Mn P S Si A-1 ≤0.27 ≤0.93 ≤0.035 ≤0.035 ≥0.10 C ≤0.35 0.29-1.06 ≤0.035 ≤0.035 ≥0.10 Mechanical properties: Grade Yield Point Mpa(ksi) Tensile Strength Mpa(ksi) Elongation A-1 ≥255(37) ≥415(60) ≥30% C ≥275(40) ≥485(70) ≥30% Tolerance for OD and WT
Tubos estriados do permutador de calor do peso 13.5mm do Od 63.5mm X
OD63.5XWT13.5 Rifled Pipe Heat Exchanger Tubes Product Name:OD63.5XWT13.5 Rifled Pipe Heat Exchanger Tubes Material Carbon steel,Alloy steel Od: 21.3-762mm: Standard DIN GB ISO JIS BA ANSI Grade: 20G,20MnG,15CrMoG,SA210Gr.A1, SA210Gr.C, SA213T12, ASTM A335P11 P91,P22,16Mo3....... Wall thickness: 2.77-25.4mm Length: 5.8/6/11.8/12mtr as required or random length Thread No.: 4ribs/6ribs/8ribs/12ribs...... Surface treatment: Black painting, oiled or galvanized Payment term; 30%
