Casa / produtos / Tubo de aço soldado

Tubo de aço soldado

Qualidade Seção oca preta retangular soldado da tubulação de aço laminado fábrica

Seção oca preta retangular soldado da tubulação de aço laminado

Black hollow section Rectangular pipe cold rolled pre galvanized welded square rectangular steel pipe T(mm) 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 10*10 12*12 16*16 19*19 20*20 25*25 30*30 32*32 38*38 40*40 50*50 60*60 63.5*63.5 70*70 75*75 80*80 90*90 100*100 120*120 125*125 150*150 200*200 300*300 350*350 400*400 T(mm) 2.0 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4_6 6_8 8_12 10*10 12*12 16*16 19*19 20*20 25*25 30*30 32*32 38*38 40*40 50*50 60*60 63.5*63.5
Qualidade Tubos de aço soltos de precisão fábrica

Tubos de aço soltos de precisão

Products Description TORICH GB/T24187 BHG1 Precision Single Welded Carbon Steel Coil Tubes for Condenser Standard GB/T24187 Material Q195 Q215 Q235 Q295 Q345 Size WT: 0.5-1.2mm; OD: 3.18-18mm; Length: 1-200m Processing W-H W-C Sureface Bright ,Copper Plated, Galvanized Or Customers'requirements Applications Condenser, evaporator, cooler tube fuel pipe of refrigeration,automobile and electric appliance industrial Test Tension Test, Flaring Test, Flange Test, Reverse Test,
Qualidade JIS G3452 SGP soldou as tubulações do tubo do aço carbono para o encanamento ordinário fábrica

JIS G3452 SGP soldou as tubulações do tubo do aço carbono para o encanamento ordinário

JIS G3452 SGP Welded Carbon Steel Pipes for Ordinary Piping Application for ordinary piping Diameter: 5-420mm, Wall thickness: 0.5-50mm Length: 12mmax Grade: SGP Standard: JISG3452 Black pipe: without zinc coating Galvanized pipe: with zinc coating Produce method:ERW Steel Grade:SGP Relevant standard: KSD3507, ASTMA53, API5L, DIN2440, DIN2441, BS1387, BS3601, JISB0203, JISB0253, JISB2301 Black pipe without zinc coating Galvanized pipe with zinc coating CHEMICAL COMPOSITION
Qualidade Único tubo de aço soldado M101 de Bundy JASO do refrigerador da parede fábrica

Único tubo de aço soldado M101 de Bundy JASO do refrigerador da parede

JASO M101 Nylon12 Coating Single Wall Bundy Tube 1. Standard SAE J526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1, SPCC, SPCD, SPCEN, ST14, ST15, ST16, DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per customer’s request 5.
Qualidade O SAE redondo J525 soldou o tubo estirado a frio recozido aço para peças de automóvel fábrica

O SAE redondo J525 soldou o tubo estirado a frio recozido aço para peças de automóvel

SAE J525 Welded Cold Drawn Low Carbon Steel Tubing Annealed for Bending and Flaring Applications: for Bending and Flaring to Auto Parts Quick Detail: Size range: O.D.:6-350mm W.T.:1-15mm L: According to customer Order Grade: Low Carbon Steel Manufacture and Production: ERW+ DOM The tubing is made from flat-rolled steel shaped into a tubular form, the edges of which are joined and fused together by electric-resistance welding. After forming and welding, the tubing shall be
Qualidade ASTM A513 Tubo de aço ERW padrão de baixo carbono para sistema de escape de camiões com gama de OD de 19-381 mm fábrica

ASTM A513 Tubo de aço ERW padrão de baixo carbono para sistema de escape de camiões com gama de OD de 19-381 mm

ASTM A513 Low Carbon Electric Resistance Welded (ERW) Steel Tube For Truck Exhaust System Product Overview ASTM A513 low carbon ERW steel tube is a cost-effective welded mechanical tubing product designed specifically for truck exhaust system applications. This tubing is ideal for straight exhaust sections, intermediate pipes, tailpipe assemblies, muffler inlet/outlet tubes, and fabricated exhaust connectors. Manufactured from low-carbon steel strip using electric resistance
Qualidade Tubo soldado aço carbono de ASTM A214 para o permutador de calor e o condensador fábrica

Tubo soldado aço carbono de ASTM A214 para o permutador de calor e o condensador

ASTM A214 is a specification that covers minimum-wall-thickness, electric-resistance-welded, carbon steel tubes to be used for heat exchangers, condensers, and similar heat-transfer apparatus. These tubes are commonly used in boilers, superheaters, and air coolers. Material and Specification The material used in ASTM A214 is carbon steel, and the tubes are electric-resistance-welded. The specification covers a range of sizes and thicknesses, as shown in the table below.
Qualidade SA178 Tubo de aço carbono-manganês soldado com resistência elétrica de grau A para trocador de calor 12,7-127 mm OD fábrica

SA178 Tubo de aço carbono-manganês soldado com resistência elétrica de grau A para trocador de calor 12,7-127 mm OD

SA178 Grade A / Grade C / Grade D Electric-Resistance-Welded Carbon & Carbon-Manganese Steel Tube for Heat Exchangers Material SA178 (equivalent to ASTM A178) is a minimum-wall-thickness electric-resistance-welded (ERW) tubing product made from carbon steel (Grade A, Grade C) and carbon-manganese steel (Grade D) . It is widely specified for boiler tubes, boiler flues, superheater flues, and safe ends , and is also commonly selected for heat-transfer service where stable weld
Qualidade Tubo soldado de Bundy da parede do tubo de aço do sistema de freio único para o refrigerador fábrica

Tubo soldado de Bundy da parede do tubo de aço do sistema de freio único para o refrigerador

SAE J526 PVF/ Copper Coating Single Wall Bundy Tube For Brake System 1. Standard SAE J526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1, SPCC, SPCD, SPCEN, ST14, ST15, ST16, DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per
