welded steel pipe
"
Tubo soldado de Bundy da parede do tubo de aço do sistema de freio único para o refrigerador
SAE J526 PVF/ Copper Coating Single Wall Bundy Tube For Brake System 1. Standard SAE J526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1, SPCC, SPCD, SPCEN, ST14, ST15, ST16, DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per
O plano tomou partido de grande resistência de superfície lubrificado soldado elíptico da tubulação de aço carbono
Welded Carbon Steel Flat Sided Elliptical Oval Tube Standard GB/T3094, BS, JIS, GB, DIN, ASTM, API Matrial 10#-45# A53-A369, ST35-ST52, Q195, Q235 , Q345 Size OD: 4-1200mm WT: 0.3-200mm Length: 1-12m Application Mechanical engineering , Agricultural machines , Structural construction Surface painted,galvanized,or oiled according to customer's requirement Test and Inspection Mechanical Test, Tension Test Flaring Test, Flattening Test Hardness Test, Hydrostatic or Nondestructiv
Pequeno diâmetro soldado do carbono do tubo de aço do freio parede dobro baixo para automóveis
Brake Double Wall Low Carbon Steel Tube J527 B Small Diameter For Automobiles Copper brazed double wall steel tube is made of steel strips which is copper plated on both sides.It has widely applied for automobiles,refrigerators and the other hydraulic system industries. Dimension and specification O.D. mm Thickness mm Weight g/m Assurance pressure kg/cm3 4.76 0.7 70.28 350 6.00 0.7 91.76 350 6.35 0.7 97.75 350 7.00 0.7 108.75 350 7.14 0.7 111.17 350 8.00 0.7 126.31 350
Os DOM 1010 de ASTM A513 tubulação de aço soldada mecânica de resistência 1020 1026 elétrica
ASTM A513 Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing Steel Grade and Chemical Compositions: Steel Grade C Mn P S Si Cr Mo max max max max min 1008 0.10 0.5 0.035 0.035 1010 0.08-0.13 0.30-0.60 0.035 0.035 1018 0.14-0.20 0.30-0.60 0.035 0.035 1020 0.17-0.23 0.30-0.60 0.035 0.035 1026 0.22-0.28 0.60-0.90 0.035 0.035 1035 0.31-0.38 0.60-0.90 0.035 0.035 4130 0.28-0.33 0.40-0.60 0.035 0.035 0.15-0.35 0.80-1.10 0.08
Quadrado oco/tubo de aço soldado retangular Erw/aço carbono sem emenda
ASTM A500 ERW Carbon Steel Gr B Gr C Hollow Square/Rectangular Steel Tube Pipe ASTM A500 ERW Carbon Steel Gr B Gr C Hollow Square/Rectangular Steel Tube Pipe Square Steel Tube Specifications: Thickness: 0.6-40mm Size: 20*20-600*600mm Material: Q195,Q215,Q235,Q345(B,C,D,E) Certification: ISO9001, BV, API, ABS Standard: ASTM GB DIN API IS EN BS Usage: Mechanical & manufacture, Steel structure, Shipbuilding, Bridging ,Automobile chassis Technique: ERW Packing: 1.Big OD: in bulk
ERW soldou o revestimento de zinco da forma redonda de tubo da tubulação de aço carbono/aço de liga
TORICH SAEJ526 PVF/Copper Coating Single Wall Bundy Tube For Brake system 1. Standard SAEJ526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1,SPCC,SPCD, SPCEN, ST14, ST15, ST16,DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per
Parede dobro tubo de aço soldado galvanizado com o revestimento de zinco para o freio do automóvel
Double Wall Galvanized Bundy Tube WithZinc Coating For Automobile Brake 1. Standard GM123M, GM124M, TS7600G, GB 11258-89 2. Steel Grade/Steel Material/Steel Number: Low carbon steel, such as SPCCBLDBLC 3. Raw Material: Cold rolled low carbon steel strip 4. Characteristic: Good Surface Quality, Uniform coating No coating burr Stable quality Excellent corrosion resistance TORICH QUALITY ASSURANCE 5. Application: Brake tube on automobile 6. Specifications: OD(mm) OD tolerance(mm
Tubo de aço ERW para tubulação comum com superfície galvanizada e OD de 30-325 mm
SGP Welded Carbon Steel Pipe (ERW Steel Tube) for Ordinary Piping Material This product is an electric-resistance-welded (ERW) carbon steel pipe designed for ordinary/utility piping —typically used to convey steam, water, oil, gas, air, and other general fluids under relatively low service pressure . Specifications Manufacturing process: High-frequency ERW longitudinal seam. Typical size range (SGP / JIS ordinary piping): OD 10.5–508.0 mm (DN 6A–500A) with corresponding
Níquel soldado de Hastelloy C276 da tubulação de aço de liga - cromo - molibdênio 8,9 g/cm3
Alloy Steel Pipe Hastelloy C-276 nickel-chromium-molybdenum alloy Welded steel pipe Hastelloy C-276 is a nickel-chromium-molybdenum alloy containing tungsten content of silicon, carbon is very low. Standard of Hastelloy C-276: ASTM B462,STM B564, ASTM B575 and so on Hastelloy C-276 is characterized by: ● In the oxidation and reduction status, for most corrosive medium has excellent corrosion resistance. ● excellent resistance to pitting, crevice corrosion and stress corrosion
