08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

Nome da marca:	TORICH
Número do modelo:	08X17H13M2T 316Ti
MOQ:	1 tonelada
preço:	negociável
Condições de pagamento:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Capacidade de abastecimento:	60000 toneladas/tonelada por ano

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Lugar de origem:

Zhejiang/China

Certificação:

ISO9001 ISO 14001 TS16949

Certificação:

ISO,SGS,Other,ROHS

Aço:

Série 300, Série 200, Série 400, Série TP316, Série 200/300

Aplicação:

serviço de alta temperatura

Tipo:

sem costura e soldados, redondos

Tipo de linha de solda:

ERW, soldada sem emenda, espiral, TIG

Padrão:

GB, ASTM, DIN, AISI, JIS

Espessura:

0.5-100mm,

Diâmetro externo:

6 a 760 mm

Comprimento:

1m-12m, 6m ou conforme pedido do cliente, 30mm ou sob medida, 0-12m,2.5-8m

Nome do produto:

Tubos de aço inoxidável,Venda rápida de tubos quadrados de aço inoxidável preço por tonelada

Superfície:

BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D

Materiais:

Série 200/300 Série/400200,202, série AISI 201,400

Forma:

Quadrado, redondo, quadrado, retângulo,

Acaba.:

Esmalte, linhas de cabelo, BA, espelho, etc., picado

Técnica:

Enrolado a frio Enrolado a quente, desenho a frio

Grau:

201/202/304/304L/316/316L/321/310s/410/420/430/440/439 etc., 201, 316L, 202, 304L, 316, 316L, 310s,

Nome:

Tubos de aço inoxidável sem costura,tubos telescópicos de aço inoxidável,tubos de água circulares co

Secundário ou não:

Não secundário

utilização:

Para Transporte de Fluidos

processo:

laminagem a quente

Teste:

Teste estendido, Teste de pressão da água,

Serviço de tratamento:

Perfurar, cortar

Amostra:

Amostragem livre

Especificação:

Personalizado

Detalhes da embalagem:

Em pacotes ou em caixas de madeira.

Habilidade da fonte:

60000 toneladas/tonelada por ano

Destacar:

316Ti Round Stainless Steel Tube

08X17H13M2T Stainless Steel Pipe

High Temperature Round Stainless Steel Tube

Descrição do produto

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 0

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

Material

08X17H13M2T is a Russian designation for a titanium-stabilized austenitic , equal to 316Ti grade. it's miles designed to be used in excessive-temperature environments in which corrosion resistance and mechanical sturdiness are essential.

Specification

Elegant: GOST 9941-80 one, ASTM A213, A312 / EN 1.4571 / JIS SUS 316Ti
Shape: spherical tube/pipe
Size: Outer diameter and wall thickness as in step with requirement, normally beginning from 6mm to 630mm diameter, with numerous wall thicknesses.
Duration: typically furnished in random or steady lengths in step with patron specifications
Floor Stop: Pickling, polished, or as requested

Key Features

incredible corrosion resistance in oxidizing and mildly lowering atmospheres
immoderate resistance to intergranular corrosion due to titanium stabilization
nicely mechanical houses at improved temperatures (as much as 870°C)
robust resistance to pitting and crevice corrosion in chloride environments
applicable weldability and formability
lengthy issuer lifestyles in immoderate temperature and stress programs

Chemical Composition

Element	C	Si	Mn	P	S	Cr	Ni	Mo	Ti	N	Fe
%	≤0.08	≤1.00	≤2.00	≤0.035	≤0.03	16.00-18.00	10.00-14.00	2.00-3.00	5×C min to 0.70	≤0.10	Balance

Mechanical Properties

Property	Value
Tensile Strength (σb)	≥520 MPa
Yield Strength (σ0.2)	≥210 MPa
Elongation (δ5)	≥40%
Hardness (HB)	≤200
Impact Toughness (ISO-V)	≥40 J (at room temperature)
Operating Temperature Range	Up to 870°C

Equivalent Grades

Country/Standard	Grade
ASTM	A182 F316Ti, A213 TP316Ti
EN	1.4571
GOST	08X17H13M2T
JIS	SUS 316Ti
GB (China)	0Cr17Ni12Mo2Ti

Application

warm temperature exchangers and boilers strolling beneath excessive temperatures
Chemical processing system uncovered to corrosive media
Furnace additives and excessive-temperature piping systems
Petrochemical corporation piping and system
Offshore structures and marine packages at risk of chloride-triggered corrosion
meals processing device in which corrosion resistance is critical
power plants and superheater tubes

This specialised 08X17H13M2T (316Ti) is exceedingly suitable for environments requiring sustained mechanical power and corrosion resistance at multiplied temperatures, making it a dependable choice for business programs disturbing sturdiness and safety.

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 1

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 2

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 4

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 6

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 7

TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and

trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and

credibility among domestic and foreign customers.

The company's production plant covers an area of over 10,000 square meters, with an annual production

capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.

The group holds shares in more than ten domestic production entities, whose main products include

seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.

Over the past 30 years, the company has been gradually developing new technologies and materials to meet

the growing needs of customers and various diversified needs, exporting to more than 56 countries and still

increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 8

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 11

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 12

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 13

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
